Details
Technical Data
| EASY-1 | EASY-2 | EASY-3 | EASY-3 "PLUS" | |
| LASER Source | Nd: YAG | Nd: YAG | Nd: YAG | Nd: YAG |
| Wavelenght | 1064nm | 1064nm | 1064nm | 1064nm |
| Avergage Power | 95W | 100W | 110W | 140W |
| Peak Power | 7,5kW | 9,0kW | 10kW | 10kW |
| Max Energy | 150 Joule | 180 Joule | 200 Joule | 200 Joule |
| Pulse Frequency | up to 30Hz | up to 30Hz | up to 30Hz | up to 50Hz |
| Pulse Duration | 0.1/20 * mS | 0.1/20 * ms | 0, 1/20 * mS | 0.1/25 ms |
| Spot Dimension | 0,2+2,0mm (0,1mm Optional) | 0, 2 + 2, 0mm (0,1mm Optional) | 0, 2 + 2, 0mm 0,1mm Optional) | 0, 2 + 2, 0mm 0,1mm Optional) |
| External Control | 10" Color TouchScreen | 10" Color TouchScreen | 10" Color TouchScreen | 10" Color TouchScreen |
| Max Working Temp. | 39°C | 39°C | 39°C | 39°C |
| Power Requirements | 1-Ph, 220/230 VAC, 50/60 Hz, 10A | 1-Ph, 220/230 VAC, 50/60 Hz, 10A | 1-Ph, 220/230 VAC, 50/60 Hz, 10A | 1-Ph, 220/230 VAC, 50/60 Hz, 16A |
| Cooling System | Forced Air & Double Radiator 6L | Forced Air & Double Radiator 6L | Forced Air & Double Radiator 6L | Forced Air & Double Radiator 6L |
| Size (W x D x H) | W 59 x D 92 x H 65 cm | W 59 x D 92 x H 65 cm | W 59 x D 92 x H 65 cm | W 59 x D 92 x H 65 cm |
| Net Weight | 49 Kg | 49 Kg | 49 Kg | 52 Kg |
